| Serial No | POWER | Vdc | Vrms | Irms(Amps) | Frequency | SPEED | DUTY CYCLE | COOLING |
|---|---|---|---|---|---|---|---|---|
| PMEC21 | 8.0 KW | 48 V | 3ϕ 31.4 V | 180 A | 60 Hz | 1775 RPM | S2/ 1 HR | IC 001 |
| PMEC21A | 8.0 KW | 48 V | 31 V | 188 A | 117 Hz | 3450 RPM | S2/60 min | IC 401 |
| PMEC22 | 12.0 KW | 72 V | 3ϕ 47.1 V | 180 A | 60 Hz | 1778 RPM | S2/ 1 HR | IC 001 |
| PMEC24 | 1.5 KW | 24 V | 3ϕ 17.1 V | 73 A | 60 Hz | 1760 RPM | S2/ 1 HR | IC 00 |
| PMEC25 | 1.7 KW | 30 V | 3ϕ 19.6 V | 30 A | 60 Hz | 1760 RPM | S2/ 1 HR | IC 00 |
| PMEC26 | 2.6 KW | 36 V | 3ϕ 25 V | 90 A | 60 Hz | 1760 RPM | S2/ 1 HR | IC 00 |
| PMEC27 | 3.6 KW | 36 V | 48 V | 3ϕ 25 V | 3ϕ 31.4 V | 120 A | 60 Hz | 1760 RPM | S2/ 1 HR | IC 00 |
| PMEC31 | 8.0 KW | 48 V | 3ϕ 31.4 V | 165 A | 60 Hz | 1775 RPM | S2/ 1 HR | IC 00 |
| PMEC36 | 12.0 KW | 72 V | 3ϕ 47.1 V | 165 A | 60 Hz | 1775 RPM | S2/ 1 HR | IC 00 |
| PMEC44 | 12.0 KW | 48 V | 3ϕ 31.4 V | 280 A | 60 Hz | 1780 RPM | S2/ 1 HR | IC 001 |
| PMEC46 | 1.7 KW | 24 V | 3ϕ 17.1 V | 70 A | 60 Hz | 1780 RPM | S2/ 1 HR | IC 00 |
| PMEC51 | 1.5 KW | 24 V | 3ϕ 16.1 V | 65 ~ 88 A | 60 | 120 | 140 Hz | 1760 | 3140 | 4200 RPM | S2/ 1 HR | IC 00 |
| PMEC53 | 7.5 KW | 72 V | 3ϕ 47.1 V | 135 A | 135 Hz | 3995 RPM | S2/ 1 HR | IC 00 | IC 001 |
| PMEC54 | 4.0 KW | 48 V | 3ϕ 31.4 V | 78 A | 60 | 100 Hz | 1760 | 3130 RPM | S2/ 1 HR | IC 00 | IC 001 |
| PMEC55 | 3.0 KW | 48 V | 3ϕ 31.4 V | 75 A | 60 | 100 Hz | 1760 | 3130 RPM | S2/ 1 HR | IC 00 | IC 001 |
| PMEC56 | 5.0 KW | 48 V | 3ϕ 31.4 V | 98 A | 60 | 100 Hz | 1760 | 3130 RPM | S2/ 1 HR | IC 00 | IC 001 |
